Biscuit Packing Machine with Auto Feeder

Home » Products » Automatic Feed Packaging Line » Biscuit Packing Machine with Auto Feeder

Model: ALD-250B

Description

The biscuit packing machine with auto feeder is efficient in feeding and labor-saving as fully automatic packaging is realized.

The new ALD-250B biscuit packing machine with auto feeder is the result of AOLIDE’s commitment to technological development and innovation. This ongoing effort brings AOLIDE a new type of machine with enhanced performance and convenience of use.

Features

1. Dual motor, Panasonic transducer and PLC controller. Bag length can be set and cut in one step, saving time and packing film. 2. Human machine interface. Parameters of this high-speed biscuit wrapping machine are easy and convenient to set. 3. Self diagnosis of failure and clear failure display. 4. High sensitivity optical electric color mark tracking. Digitally input cut position, making the sealing and cutting position more accurate. 5. Separate PID control over temperature, making it more suitable for various packing materials. 6. The biscuit packing machine with auto feeder can stop in selected position without sticking to cutters and waste of packing film. 7. Simple drive system to realize more reliable operation and easier maintenance. 8. All the controls are achieved by software, facilitating function adjusting and upgrading.

Parameters

Machine Model ALD-250

BA
Max. Film Width 250 mm
Bag Length (mm) 90 to 220 150 to 330
Bag Width (mm) 30 to 110
Product Height Max. 55 mm
Film Roll Diameter Max. 320 mm
Packing Speed 40 to 230 packs/min
Power 220 V, 50/60 Hz, 2.4 kW
Machine Size (mm) (L) 3770 × (W) 670 × (H) 1450
Machine Weight 600 kg
